*Aluminum is lightweight and has excellent corrosion resistance.
*Smooth finishes have more attractive and are easier to clean.
Thickness Information:
– 016″ (0.4mm): Considered the standard for industrial use and recommended on pipelines up to 24″ O.D., which includes the insulation. Primarily used to protect piping, vessels, and tanks that are less than 8 feet in diameter.
– 020″ (0.5mm): Applicable for insulation lines up to 36″ O.D., including insulation. Primary use to protect towers, vessels, and tanks with a diameter greater than 8 feet.
– 024″ (0.6mm): Heavier gauge roll jacketing where extra strength and protection is required.
– 032″ (0.8mm): For areas where extra protection is required, or in custom fabrication of Box covers, tank heads, or heavy wear areas.
Smooth Aluminum Roll Jacketing Manufacturers, Factory, and Suppliers From China, We are sincerely looking forward to cooperating with buyers all around the world.
*SURFACE BURNING CHARACTERISTICS ASTM E 84
*FLAME SPREAD INDEX 0
*SMOKE DEVELOPED INDEX 5
| Alloy | Si | Fe | Cu | Mn | Zn | Mg | Ti | Cr | Other Elements | Total | Al |
| Each |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.05 | 0.03 | 0.03 | – | 0.03 | | 99.6min |
| 1100 | Si+Fe=0.95 | 0.05-0.20 | 0.05 | 0.1 | – | – | – | 0.05 | 0.15 | 99.0min |
| 3003 | 0.6 | 0.7 | 0.05-0.20 | 1.0-1.50 | 0.1 | – | – | – | 0.05 | 0.15 | reminder |
| 3105 | 0.6 | 0.7 | 0.3 | 0.30-0.80 | 0.4 | 0.20-0.80 | 0.1 | 0.2 | 0.05 | 0.15 | reminder |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.25 | 0.50-1.10 | – | – | 0.05 | 0.15 | reminder |
Ecoin aluminum sheet can be used as (application):
• Aluminum Jacketing is recommended for HVAC, Insulated Piping, tanks & vessels less than 8 feet in diameter.
• Deep corrugated sheets are recommended for diameters greater than 8 feet.
• Chemical Plants & Refineries: Distillation columns, tank farms, fractionation units, cokers, and ethylene production units.
• Paper Mills: Chemical storage tanks, breechings, and ducts.
• Steel Mills: Pickle acid tanks, oxygen production units, fuel oil, and tar storage tanks.
• Miscellaneous: Power stations, Food processing plants, LPG storage units, LNG storage units, sewage, and wastewater treatment plants.
