*One product for several final thicknesses
*Excellent mechanical properties (such as tensile, compression and shear) when used as lamellas
*Non-combustibility (Euroclass A1)
*Fire-resistance, with melting point above 1000 °C
*Excellent acoustic insulation properties
*Good thermal insulation properties
*Dimensional stability
Mineral Wool Lamella
Ecoin Mineral Wool Lamella is a rock mineral wool product cut from Board.
Due to its optimal thermal, fire, acoustic, and mechanical properties, PBE Lamella represents the perfect insulation solution for producers of high-performance prefabricated sandwich panels that do not have their own line for cutting lamellas from rock mineral wool boards.
Lamellas can be customized according to specific customer requirements.
Raw materials: Basalt, dolomite
Width: 50-60-70-75-80-90-100mm
Thickness: 150mm
Length: 1.2m
Other sizes can be customized upon request
Asbestos: 100% Non Asbestos
Mineral Wool Lamella Manufacturers, Factory, and Suppliers From China, We are sincerely looking forward to cooperating with buyers all around the world.
| Properties | ELTR80 | ELTR100 | unit |
| Density | 100 | 120 | kg/m3 |
| Compressive Strenglh(Perpendicular to Fiber) | – | – | kPa |
| Compressive Strenglh(Parallel to Fiber) | 80 | 100 | kPa |
| Tensile Strength (Perpendicular to Surface) | – | – | kPa |
| Tensile Strength (Parallel to Fiber) | 150 | 200 | kPa |
| Thermal Conductivity(Average Temperature25℃) | <0.047 | <0.047 | W/mK |
| Fire Performance | Reaction to fire-Class A1 | — | |
| Water repellence | >99 | >99 | % |
| Water absorption(Partial immersion) | <0.5 | <0.5 | kg/m2 |
| Moisture absorption | <0.5 | <0.5 | % by volume |
| Dimensional stability | <0.5 | <0.5 | % |
| Vapour diffusion resistance factor u | Approximately equal to 1.5 | Approximately equal to 1.5 | – |
| Melting Point | ＞1000 | ＞1000 | ℃ |
| Acidity Coefficient | ≥1.8 | ≥1.8 |
*Sandwich panel
*H bar core insulation
*Fire barrier
